Suggestions for Mounting Euroquatics Angels and Populargrow Light Bars

[griss]

Some of you are aware I'll be upgrading tanks in the future. On the 150 gallon tank, I'm going to run (6) Euroquatics Angels and also got (2) Populargrow Blue 108w light bars. I'm looking for suggestions on how to mount these 8 fixtures over a 60" x 26" x 24" tank.



[Reefing102]

Have you thought about maybe doing a canopy or even a floating canopy?

Or there’s custom building a light stand using T-Slot aluminum (I don’t know much on this though).



[griss]

Have you thought about maybe doing a canopy or even a floating canopy?

Or there’s custom building a light stand using T-Slot aluminum (I don’t know much on this though).

Honestly, it’s all up in the air right now. I’m just looking for different ideas. Floating canopy will definitely be considered.

The tank is going to be below where I framed around the duct work so, once in place, there won’t be a ton of room above.



[kharmaguru]

So what is the layout going to be? I assume a blue strip down each outer edge but what configuration do you intent for the 6 fixtures? Do they need to be adjustable?

BTW this sounds really blue considering you don't like blue.



[griss]

So what is the layout going to be? I assume a blue strip down each outer edge but what configuration do you intent for the 6 fixtures? Do they need to be adjustable?

BTW this sounds really blue considering you don't like blue.

This might be hard to explain in words. The Angels will be parallel to the tank 2 on the left, 2 center and 2 on the right. The Bars will be behind the back angels and in front of the front Angels. I will likely get a third (maybe whiter) bar and put it between the front and back Angels.

Re: really blue, maybe. Right now the way I’m running the Angels it looks crisp old school 10k and I have the whites pretty low compared to the blues, so I guess I’ll see.



[griss]

Hmmm, wonder if these would work. I'd need three.

Orphek Universal Fixing Bracket Kit

Shop/Buy Orphek Universal Fixing Bracket Kit is designed specifically for the installation and positioning of Orphek OR3 LED bars. Versatile, anti-rust, heavily-built, multi-functional and really easy to install. You can install a mix of Orphek products or assembly 7 Orphek OR3 LED Bars with it.

shop.orphek.com



[griss]

Okay, after watching this I think I'd like that type of setup. But, being a recent convert from MH to LED, I have no idea where to begin. Any suggestions are appreciated.



[Reefing102]

If you want that exact set up, he’s running the ecotech multi light rail system - if you click “buy” it will show you the various parts available. From the mounts to the various rail sizes and x mounts.

Radion Accessories - EcoTech Marine

Mounting and Hanging Kits for your Radion LED lights

ecotechmarine.com

Beyond that, it looks like he just bought spare RMS rail and used those magnets to attach to the multi-light rail system.

So for your set up, if you went with the ecotech stuff you’d need the end brackets and the
XR703-0705 70.5 inch track. From there, if you use additional RMS Rail I’d imagine 2 tracks per two lights (one on each side), so 6 additional track of the 20.5 inch track. Plus the magnets.

As he mentions in the video, since those magnets have 3m tape, you can use other brands of tracks if you wanted (extruded aluminum, whatever Amazon sells, etc), I’d just ensure it’s thick to support the weight of the lights.

Maybe, and not trying to spend money, But consider two sets of end brackets and 70.5 track, then have custom mounts 3D printed for the angels and then do two pieces of additional track to add the PopBloom bars.



[Reefing102]

I’m not 100% certain, and perhaps @Sugar Magnolia may be able to chime in as I think they have experience with it, but extruded aluminum/t-slot may get you what you want with a similar look at a lower cost.



[griss]

I’m not 100% certain, and perhaps @Sugar Magnolia may be able to chime in as I think they have experience with it, but extruded aluminum/t-slot may get you what you want with a similar look at a lower cost.

Okay, help me out. Where would I look for generic T-slot rail and how would I know what I want. I'm thinking something suspended from the ceiling that I could put on a pulley type system to raise and lower as needed.



[Reefing102]

Here’s the best thing I’ve found on it. I just haven’t had the “need” yet to try to build anything

https://www.reef2reef.com/threads/guide-to-diy-with-t-slot-aluminum.903885/



[wvned]

I think hanging lights over a fish tank with magnets is one of the stupidest things I have ever heard.

80/20
8020.net Never had Lego blocks?
just like them. All shapes and sizes.



[JCOLE]

Okay, help me out. Where would I look for generic T-slot rail and how would I know what I want. I'm thinking something suspended from the ceiling that I could put on a pulley type system to raise and lower as needed.

I built my canopy for my 500 from all T-slot. I purchased the T-slot and all connectors, screws, etc from Amazon. Really light, doesn't rust, and strong.
