Building the BTA Propagation System (Part 2)
Building the BTA Propagation System (Part 2)
First step today was to clean all of the tanks with white vinegar. Once squeaky clean I set them up on some cinder blocks and 2x4s so I could hammer them out in quick secession. I also won't need to move them until this is done.
I placed an insert into each tank and squared them up.
Once square I used a razor blade to notch out the trim so that the inserts could be inserted straight down. This will really simplify installation.
Now that I know where they will go I crawl under the tanks and use a sharpie marker to draw lines down the middle of the acrylic, this is how I will position the silicone application.
Ready to go!
I'll be using Momentive RTV103. This is a strong black silicone adhesive. If you haven't ever used it before it is thick and skins over quickly so you need to work fast.
I move all of the inserts out of the way, cut the tip, and apply a bead of silicone along my lines. Each tank is done one at a time to minimize any skinning effect.
I carefully and quickly slide the insert down through the top notches and align it to the silicone. Once in place I will square it up within reason. It is best not to move it so if it's close (they all were) I left it. I wanted to see silicone squeeze out on both sides of each pane. I will trim this once it cures.
I will wait for the silicone to cure before going any further. I don't want to shift the inserts. Once cured I will do the sides via the injection method. Since this is just an insert it won't have much load on it and I am using a high end silicone. Otherwise I would recommend against the injection method.
