Pelagic7's new LED fixture

[pelagic7]

I'm planning to DIY a 48" 72x3W LED fixture.

Here's my shopping list.

Name Quantity(including some spare parts)

LED
Royal Blue XP-E 44
Blue XP-E 6
Neutral White XP-G 16
Cool White XP-G 9
Xp Optical 60 72

PS
CLG-150-48A 48V,3.2A(800mAx4), for blues
CEN-75-42A 42V, 1.8A(900mAx2), for whites
15A PS Plug 2

Parts
Arctic Alumina Thermal Adhesive 5g 3
8.46"x18" heatsink 2
Resistors 7
1A Fuses for Blue 6
1.5A Fuses for white 6
Terminal Block 4 positions 4
Terminal Block Jumper 10
OEM Digital Multimeter DT-830B 1

I am still thinking what to use to hold the heatsinks.

few questions
1. Anything else I should get?
2. what's your though on the power supplies I pick?

Thanks.



[poolkeeper1]

Cheng, They have Thermal tape now to mount your LED's with much easier and cheap.
Like to see you at the next meeting, Are you a member?
Bill



[pelagic7]

Yes Bill, I am a member, sorry I wasn't able to attend the last meeting to vote for you.
I will look into the Thermal Tape option.

Thanks.



[poolkeeper1]

Thanks

Thanks

Yes Bill, I am a member, sorry I wasn't able to attend the last meeting to vote for you.
I will look into the Thermal Tape option.

Thanks.

No vote taken! No one else wanted the Job Ha!
Bill



[pelagic7]

here's the final shopping list
Quantity name Unit Price Price
44x Royal Blue XP-E $3.19 = $140.36 http://www.clay-boa.com/categories/CREE/XP%2dE/
6x Blue XP-E $4.08 = $24.48 http://www.clay-boa.com/categories/CREE/XP%2dE/
16x Neutral White XP-G $4.87 = $77.92 http://www.clay-boa.com/categories/CREE/XP%2dG/
9x Cool White XP-G $5.07 = $45.63 http://www.clay-boa.com/categories/CREE/XP%2dG/
72x Xp Optical 60 $1.49 = $107.28 http://www.clay-boa.com/categories/Optics/

2x CEN-75-48,48V,1.57A(700mAx2) $59.69 = $119.38 http://wattsupply.com/s.nl/it.A/id.2498/.f
1x CEN-100-42,42V, 2.28A(1Ax2) $64.09 = $64.09 http://wattsupply.com/s.nl/it.A/id.3180/.f
1x Shipping $15.00 = $15.00

3x 15A PS Plug $2.50 = $7.50 http://www.rapidled.com/servlet/the-47/3-dsh-Prong-Power-Cord/Detail
2x 4.25" x 23" heatsink, drilled $60.00 = $120.00 http://www.rapidled.com/servlet/the-96/Drilled-and-Tapped-4.25"/Detail
2x Arctic Alumina Thermal Adhesive 5g $5.50 = $11.00 http://www.rapidled.com/servlet/the-108/Thermal-Grease-(5g)/Detail
8x Wire Connectors/Nuts $0.75 = $6.00 http://www.rapidled.com/servlet/the-48/Wire-Connectors-fdsh-Nuts/Detail
1x 4 Hook Wire Hanging kit $10.00 = $10.00 http://www.rapidled.com/servlet/the-109/4-Hook-Wire-Hanging/Detail
1x AA Battery LED Tester $2.00 = $2.00 http://www.rapidled.com/servlet/the-140/AA-Battery-LED-Tester/Detail

10x 1A Fuses for Blue $0.69 = $6.90 http://search.digikey.com/scripts/DkSearch/dksus.dll?Detail&name=F3169CT-ND
6x 1.5A Fuses for white $0.60 = $3.59 http://search.digikey.com/scripts/DkSearch/dksus.dll?Detail&name=F2319-ND
6x Terminal Block 2 Curcuits $0.59 = $3.54 http://search.digikey.com/scripts/DkSearch/dksus.dll?Detail&name=A98503-ND
10x Terminal Block Jumper $0.23 = $2.32 http://search.digikey.com/scripts/DkSearch/dksus.dll?Detail&name=A0139-ND
10x Resistors $0.91 = $9.10 http://search.digikey.com/scripts/DkSearch/dksus.dll?Detail&name=PPC5D1.0CT-ND
1x Shipping $5.00 = $5.00

1x 20 gauge wire 100 ft $9.50 = $9.50 http://www.bulkwire.com/wire-cable/stranded-hookup-wire-300v-ul-1007-1569.html
1x Shipping $9.15 = $9.15

1x OEM Digital Multimeter DT-830B $6.96 = $6.96 http://www.clay-boa.com/products/OEM-Digital-Multimeter-DT%2d830B.html
1x Aoyue 937+ Soldering System With 3 Bonus Iron Tips $68.75 = $68.75 http://www.amazon.com/gp/product/B004B6GGS4/ref=ord_cart_shr?ie=UTF8&m=A35TOPIEYAQ7RQ

Wire stripper for 20 gauge
1x Solder it $3.47 = $3.47 http://www.lowes.com/pd_23528-64827...er+it&pl=1&currentURL=/pl__0__s?Ntt=solder+it
1x 60-40 Rosin Core Solder (8 Ounces) $11.45 = $11.45 http://www.homedepot.com/h_d1/N-5yc...splay?langId=-1&storeId=10051&catalogId=10053
2x Acrylic Sheet 0.093 18*24 $10.67 = $21.35 http://www.homedepot.com/h_d1/N-5yc...splay?langId=-1&storeId=10051&catalogId=10053
4x Uchannel $11.98 = $47.94 http://www.homedepot.com/h_d1/N-5yc...splay?langId=-1&storeId=10051&catalogId=10053



references I am using
http://reefcentral.com/forums/showthread.php?t=1678127&page=200
http://www.reefcentral.com/forums/showthread.php?t=1952442
http://www.rapidled.com/servlet/the-Hanging-Kits/Categories
http://www.nanotuners.com/
http://www.canreef.com/vbulletin/showthread.php?t=70413



[orthokardia]

Cheng,
I love your level of detail. you put a biblio on a forum post that rocks!



[poolkeeper1]

Too much free time on his hands as far as i can tell LOL
Bill



[Jennifier615]

So what is the grand total Cheng? I am interested and want to go to the LED's hopefully by the time my halides are due for a change. I would rather spend money on a new fixture with better light output then spend 500 for bulbs for expensive juice eating lights.



[pelagic7]

Too much free time on his hands as far as i can tell LOL
Bill

lol it took me like 4 weeks to come out w/ the list. lol
total is around 800-850 or so if you don't count the one time cost.



[NeveSSL]

Cheng, check out the drivers from Nano-Tuners. They're much more efficient than the meanwells. They have some for $80 that will do 30 LEDs each. They're dimmable, too.

Brandon



[pelagic7]

Too late. hehe thanks for the info thou.

The drivers I got are around 90% eff, I could pay more and get something high eff, than I thought about if I want to pay $30 for $2% more eff? hehe. I went w/ cheap one, 24 per driver just in case I screw up.



[NeveSSL]

Cool.

Brandon



[ZachB]

here's the final shopping list
Quantity name Unit Price Price
44x Royal Blue XP-E $3.19 = $140.36 http://www.clay-boa.com/categories/CREE/XP%2dE/
6x Blue XP-E $4.08 = $24.48 http://www.clay-boa.com/categories/CREE/XP%2dE/
16x Neutral White XP-G $4.87 = $77.92 http://www.clay-boa.com/categories/CREE/XP%2dG/
9x Cool White XP-G $5.07 = $45.63 http://www.clay-boa.com/categories/CREE/XP%2dG/
72x Xp Optical 60 $1.49 = $107.28 http://www.clay-boa.com/categories/Optics/

clay-boa.com is a rather unusual (LED?) site :lol:

Nice list. Look forward to seeing the build.



[GT_Jacket]

www.clay-boa.com

Sounds like too much fiber to me



[NeveSSL]

LOL... wow... I suppose RC was trying to have a sense of humor about that site... interesting.

Brandon



[Pickupman66]

wow.. thats funny....



[ZachB]

It would take some serious fiber to move that one.



[pelagic7]

<a href="http://www.flickr.com/photos/pelagic7/5528488576/" title="new light 1 by pelagic7, on Flickr"><img src="http://farm6.static.flickr.com/5016/5528488576_3e18450141.jpg" width="500" height="374" alt="new light 1" /></a>

<a href="http://www.flickr.com/photos/pelagic7/5528488168/" title="new light 2 by pelagic7, on Flickr"><img src="http://farm6.static.flickr.com/5291/5528488168_f03d081c3f.jpg" width="500" height="374" alt="new light 2" /></a>

waiting for the led... and I don't expect there will be too much heat for the heat sinks, so I only got 2 stealth fans



[poolkeeper1]

Hey Cheng, What size tank are you putting this on? At only 4.25" wide you will not get much spread of the light. Or are you putting 2 side by side? Just curious.
Bill



[pelagic7]

110g, 48x18x31

I thought about that..

1. The leds will have 60° optics,
2. plus the fixture will be 4.24" wide,
3. My tank is 18" wide.

=>
1. The light fixture needs to cover 18/2-4.24/2=6.88" for each side
2. highet required to cover 6.88" = 6.88 tan60°= 6.88*1.73=11.90"

=>
As long as the coral is 12" or further from the fixture, it will get the light.
In my case, the fixture will be 10" from the surface of the water, so it should be fine...
