mr pink floyd
New member
its hard to find a thread lately without him proving us all to be idiots with his greater knowledge of all that is talked about on RC
Tunze nano mod
- Thread starter mr pink floyd
- Start date
RichConley
New member
GSMguy, I'm not trying to pick a fight.
I'm just asking, whats the point? Everyone buys Tunzes because you dont have to mod them. If you're gonna hack the pump apart, why not buy something thats cheaper, and has a higher ceiling. Building ball shaped housings for a MJ wouldnt be much harder than the DIY work you guys are doing in here.
I can see the merit of working on the controllable 6055, but the noncontrollable ones just seem like a waste of time.
I'm just asking, whats the point? Everyone buys Tunzes because you dont have to mod them. If you're gonna hack the pump apart, why not buy something thats cheaper, and has a higher ceiling. Building ball shaped housings for a MJ wouldnt be much harder than the DIY work you guys are doing in here.
I can see the merit of working on the controllable 6055, but the noncontrollable ones just seem like a waste of time.
I hope this is going to work. Thank you GSMGuy for the headsup.
First some stats for my tank. It is a 120g semi-circular (bowfront) at 30" tall. The tank back wall is 50"x30" tall, the deepest part of the tank (front to back at center) is 25".
The pump is placed at the upper corner about 1" below waterline, pointed 30 degree down at the front curved glass, the flow hits the front glass then follows along the curve traveling about 7' down to the opposite lower corner, no other pump was running when the video was shot and the pump was doing about 2,600gph since I had to turn it down a little with my controller to keep the total watts at or below 28W.
BTW, this was my very first attempt at shooting a video on the fly so please excuse me for the poor quality:
First some stats for my tank. It is a 120g semi-circular (bowfront) at 30" tall. The tank back wall is 50"x30" tall, the deepest part of the tank (front to back at center) is 25".
The pump is placed at the upper corner about 1" below waterline, pointed 30 degree down at the front curved glass, the flow hits the front glass then follows along the curve traveling about 7' down to the opposite lower corner, no other pump was running when the video was shot and the pump was doing about 2,600gph since I had to turn it down a little with my controller to keep the total watts at or below 28W.
BTW, this was my very first attempt at shooting a video on the fly so please excuse me for the poor quality:
RichConley
New member
<a href=showthread.php?s=&postid=9870577#post9870577 target=_blank>Originally posted</a> by GSMguy
i like that they are pointable,black and come with a magnet and yes the 6055 is going to be quite cool no maxi mod can do what it can. im still not sure i wouldent rather just have a vortech instead of all these nanos
Pointable, black, and magnet, can all be done on a maxijet, for less than the nanos cost.
As to controllability, I hear you. I dont think it makes a big difference, but people love it, so I can see the draw. The 6055s I can see modding for the controlability, but once you start hacking up the shroud, the motor is all that matters, and the smaller ones dont offer much more than the MJ.
Of course you were, by using a set of falsed data: 3000gph@11W?
Why can't people buy 6025 at $62, enjoy the best CS you can get, covered by the 2-year warranty, and pump out 1,250 gph at 7W? And the whole mod takes only 5 minutes, you get the best looking small stream pump on the market.
BTW, an MJMod with all the parts and mag holder and splash guard will cost you more than $62 and it is bigger and uglier IMO.
The only item that voids the warranty is my 6055 super mod.
RichConley
New member
Jmacyoung, my data is in no way false, and I'm insulted that you'd say it is. Seriously, these thigns have been tested many times. Do your research before making accusations.
I can go dig up my parts list, but its actually under $40 for maximod with mag holder, etc.
I can go dig up my parts list, but its actually under $40 for maximod with mag holder, etc.
RichConley
New member
<a href=showthread.php?s=&postid=9870768#post9870768 target=_blank>Originally posted</a> by jacmyoung
Let me put it very simply for you, if you can do 3,000gph at 11W for $40, yet everyone is spending $300 to $800 for the same pump, either the world is mad or you are, but you can only pick one
Umm.sure. You mean the same way everyone is paying $600 for a small deltec skimmer that can't keep up with a $300 bubblemaster? Price has nothing to do with performance.
GSMGuy, I asked a question. Chill out.
I just wanted to point out that if people are looking for a cheap way to get big flow, this isnt it. If you've already got nanostreams, sure.
I thought this place was about discussion. Apparantly I was mistaken.
A couple of pointers: You'd get more flow if you closed off that last opening on the pump. Its too far forward, and isnt acting as an intake. You'd also be better off opening the slits on the bakc of the pump up some more.
burton14e7
New member
I'm in no means trying to argue but could you provide us a link that shows the 3000gph. It sounds pretty amazing and I'd like to see it. But you know...a bmw driver will never drive a mercedes regardless of performace
skydancer
New member
Hey Rich,
I have two modded MJ1200's and I agree with you on the flow rate. I don't know about 3000GPH at 11W but they do put out quite a bit of water.
But please keep in mind that size is IMPORTANT to some people, like me. I like the powerhead (nanostream) to be half the size of the MJmod. It JUST looks better in my tank. I prefer the corals to take up more space than the powerheads. So, I'm sorry but the $40 argument in a hobby that costs thousands just to get in it, is absolutely miniscule. For God's sake, we pay 50 bucks on a coral!!! that can die in 1 day...
Last edited:
The last opening got another 200 gph out of the pump, I have my bag test to prove it. I don't want to touch anything in the back because I still stand a chance to replace the part if it goes down, maybe not under warranty but repair or replacement cost is discounted by Roger.
How about your MJMods?
The fact of matter is all these mag-driven pumps are the same principle, you can make them as efficient as possible but not by much, for you to claim that your MJMod can do 3000 at 11W, when the 6100 does 3200 at 45W, the Vortech 3000 at 35W and the 6055mod 2600 at 28W, perhaps you need to double check your test equipment.
Last edited:
Rich, to be fair your point of not opening slits in front of the prop is valid, I am not disputing that, only that you did not pay attention to the fact that the tips of my prop are still in front of even the last opening, right in the face of the screen. It is as compact a design as you can get.
And since you were also in the Tunze vs. Vortech thread using the Tunze 6060 to prove your point about your MJMod, I feel compelled to straighten things out a little for you.
The 6060 is rated 1500gph with a 11W motor, the MJ1200 has a 20W motor and can be over driven to 30W (talk about inefficient design) so the comparison is totally flawed.
And the point of how far the jet stream can reach is highly dependent on the size of the nozzle. For example my modded 6025 at 1250 gph can reach as far a point as my modded 6055 with a 1.5" coupler nozzle at 2600gph, because the 6025 nozzle is half the size of my DIY large nozzle, so the velocity exiting the nozzle is the same and the flow reach is the same.
Can you therefore conclude my modded 6025 is as powerful as my modded 6055?
Give it a rest Rich, MJMods were a great DIY project by some of our brilliant members, and many of us had tried and benefited from them, but its time has passed.
And since you were also in the Tunze vs. Vortech thread using the Tunze 6060 to prove your point about your MJMod, I feel compelled to straighten things out a little for you.
The 6060 is rated 1500gph with a 11W motor, the MJ1200 has a 20W motor and can be over driven to 30W (talk about inefficient design) so the comparison is totally flawed.
And the point of how far the jet stream can reach is highly dependent on the size of the nozzle. For example my modded 6025 at 1250 gph can reach as far a point as my modded 6055 with a 1.5" coupler nozzle at 2600gph, because the 6025 nozzle is half the size of my DIY large nozzle, so the velocity exiting the nozzle is the same and the flow reach is the same.
Can you therefore conclude my modded 6025 is as powerful as my modded 6055?
Give it a rest Rich, MJMods were a great DIY project by some of our brilliant members, and many of us had tried and benefited from them, but its time has passed.
Last edited:
Just got my pocket multimeter test gear, did some probing.
When the controller was at 100%, the Kill-A-Watt reported on the AC end 28W and 440mA (transformer max is 800mA), the pocket meter reported on the DC side 0.93A and 24V. The 24V was just set by the transformer when at full speed.
When the controller was at 30%, AC end was 13W and 220mA, DC end was 0.43A (volts not checked).
So the motor is drawing 0.93A max, still some ways from the 1.2A max current. And the motor was drawing a little over 22W, the transformer was drawing close to 6W. I assumed the controller draw was negligible.
I think I am safe?
When the controller was at 100%, the Kill-A-Watt reported on the AC end 28W and 440mA (transformer max is 800mA), the pocket meter reported on the DC side 0.93A and 24V. The 24V was just set by the transformer when at full speed.
When the controller was at 30%, AC end was 13W and 220mA, DC end was 0.43A (volts not checked).
So the motor is drawing 0.93A max, still some ways from the 1.2A max current. And the motor was drawing a little over 22W, the transformer was drawing close to 6W. I assumed the controller draw was negligible.
I think I am safe?
Last edited:
bergzy
New member
let the pictures decide which one would rather have in their main display?
mj mods:
nothing against mj mods btw. this is just a pictorial comparison. mj mods serve those who prefer the mj mods.
quote from mj mods website: ' A MJ 900 can be modified from 250 GPH to 1500 GPH and the MJ 1200 can be modified into an incredible 2,400 GPH pump.'
mj mod total cost without shipping for:
mj 1200+mod kit+ball holder=$80.97
i did not use their basic magnet holder price because they are not adjustable. i put a mj 1200 (non modded on my kill-a-watt) drew 20 watts. i do not know if modding them lowers their wattage usage.
tunze 6025 (internal shroud modification would not be noticeable):
total cost $61.84
http://www.marinedepot.com/md_searchitem.asp?strSearch=nanostream
i did not include prices for tools as this would basically be tough to impossible to determine what y'all have.
